SINGLE STAGE |
* Oil circulated vacuum pumps |
 |
 |
|
|
 |
|||||||||||||||||||||||||||||||||||||||||||
|
|||||||||||||||||||||||||||||||||||||||||||
* Dry running vacuum pumps(application for Money Counting machine)
| SPECIFICATION/MODEL | SML-140 | SML-280 | |
| Nominal displacement(m3/h) | 50Hz | 6.8 | 13.6 |
| 60Hz | 8.4 | 16.8 |
|
| Ultimate pressure(mmHg) | 660 | ||
| Motor version(1~, V) | 50Hz | 220 | |
| 60Hz | |||
| Nominal motor rating(1~, kW) | 0.25 |
||
| Nominal motor speed(min) | 50Hz | 1,410 | |
| 60Hz | 1,700 | ||
| Capacity(micronF) | 15 | ||
| Sound level(dB) | 53 | ||
| Approx. weight(kgs) | 10 | 13.5 | |
* Dry running vacuum pumps(application for Money Cunting machine)
| SPECIFICATION/MODEL | DEN-400 | |
| Nominal displacement(m3/h) | 50Hz | 20 |
| 60Hz | 24 | |
| Ultimate pressure(mbar) | 149 | |
| Motor version(1~, V) | 50Hz | 220 |
| 60Hz | ||
| Nominal motor rating(1~, kW) | 0.95 |
|
| Nominal motor speed(min) | 50Hz | 2,850 |
| 60Hz | 3,430 | |
| Sound level(dB) | 62 | |
| Operating temperature(กษ) | 40 | |
| Water requirements(งค/min) | 1.9 | |
| Approx. weight(kgs) | 20 | |
